Lattice Boom Winch Attachment for Telehandlers

Bild 0 einer Mietmaschine vom Typ Lattice Boom Winch Attachment for Telehandlers
Vorschaubild 0 einer Mietmaschine vom Typ Lattice Boom Winch Attachment for Telehandlers

Technical data

Below you will find all product details.

Article designation
Lattice Boom Winch Attachment

Telehandler Lattice Boom Winch for Hire

With the lattice boom winch attachment, a rotating telehandler becomes a fully fledged crane replacement. The lattice jib extends the reach of the telescopic boom over obstacles, while the integrated cable winch handles controlled lifting and precise positioning of the load. Heavy components can thus be lifted, moved and set down at the installation position without a separate mobile crane. Luibl Rental hires out the lattice boom winch as an attachment for rotating telehandlers, with delivery across Europe.

What is a lattice boom winch?

The lattice boom winch combines two functions in one attachment: the lattice jib for extending horizontal reach and the hydraulic cable winch for lifting loads vertically. Unlike a simple lattice jib with a load hook, the integrated winch allows the cable to be paid out and wound in under control, even into areas that the telescopic boom alone could not reach, such as deep shafts or areas behind building projections.

The lattice jib makes it possible to reach across horizontally: loads can be set down beyond flat roofs, balconies or gables, a function that neither a load hook nor a simple cable winch mounted directly on the boom head can provide.

Technical specifications

  • Load capacity: 800 to 2,000 kg, depending on configuration and carrier machine

  • Cable length: 3 m usable length

  • Compatibility: exclusively for rotating telehandlers with a 360° slewing superstructure

  • Mounting: via hydraulic quick-coupling system directly from the operator's cab

Applications

In many project situations, the lattice jib with cable winch replaces a costly mobile crane:

  • Building and industrial construction: placing steel beams, precast concrete elements and roof trusses over building edges

  • Installation work: precise placement of building services, ventilation systems or machine components in shafts and basements

  • Bridge construction and civil engineering: lowering heavy loads into shafts or below bridge level

  • Infrastructure projects: placing pipes, pumps and units at hard-to-reach installation positions

  • Roofing work: lifting material over roof edges and gables without repositioning the machine

Lattice boom winch vs. mobile crane: when is a telehandler worthwhile?

For medium-duty crane work up to 2 t that does not justify permanently stationed lifting equipment, a rotating telehandler with lattice boom winch offers clear advantages: the machine is mobile and suitable for rough terrain. It can be operated from a fixed position or while travelling. Where a mobile crane requires lead time and external personnel, the rotating telehandler with lattice boom winch steps in flexibly.

All other attachments are listed in the overview of telehandler attachments.

FAQ: Hiring a lattice boom winch for telehandlers

Which telehandlers is the lattice boom winch suitable for?

The attachment is suitable exclusively for rotating telehandlers with a 360° slewing superstructure. Fixed telehandlers are not compatible with this attachment.

What is the difference between a lattice jib and a lattice boom winch?

A lattice jib extends the reach of the telescopic boom horizontally. The lattice boom winch additionally contains a hydraulic cable winch for controlled lifting and lowering of the load, making it more capable than a plain jib with a load hook.

What is the load capacity of the lattice boom winch?

Depending on the carrier machine and configuration, 800 to 2,000 kg. The exact load capacity as a function of lift height and boom position can be found in the load chart of the respective rotating telehandler.

Can I hire a telehandler and lattice boom winch together from Luibl Rental?

Yes. Luibl Rental hires out rotating telehandlers and matching attachments as a complete package, with delivery across Europe using its own low-loader fleet.

Request a lattice boom winch for rotating telehandlers now: Luibl Rental provides fast advice and delivers across Europe.

Check availability and request a quote now.
