Telehandler attachment rental

A telehandler without attachments is a lifting machine. With the right range of attachments it becomes a crane, an aerial work platform, an excavator, a bucket loader and a cleaning machine – on the same chassis, on the same working day. The hydraulic quick coupler is not an accessory but system architecture: it defines how many specialised machines a single telehandler can replace in the fleet.

Technical principle

The hydraulic quick coupler sits on the boom head. Two hydraulic cylinders tension a locking profile that engages in the standardised mount of every compatible attachment. Attachment changes without leaving the cab, without tools, in under 60 seconds. Hydraulic connections couple automatically when locking; electrical connectors for scales or controls do as well.

CE conformity of the combination: the overlooked legal point

This is the most common compliance error in telehandler operation: it is not only the carrier machine and not only the attachment that must be CE compliant – but the combination of both. The Machinery Directive 2006/42/EC treats carrier and attachment as a complete machine as soon as they work together.

Consequences for the buyer:

• Third-party attachments without manufacturer approval for the specific carrier machine can void the CE conformity of the whole system

• Inspections and tests of technical equipment (Decree No. 508/2009 Coll.) include all attachments in use; unlisted attachments lead to objections

• In the event of damage, the operator is liable if non-approved combinations were used

Luibl supplies only attachments with manufacturer approval for the respective carrier machines and with complete CE documentation for the combination.

Pallet forks – basic equipment

Standard version with fixed fork width for Euro pallets (800 x 1,200 mm). Decisive when choosing: the residual capacity after the attachment's own weight. A 4 t fork carriage itself weighs 180 – 320 kg; this weight is deducted from the carrier machine's load chart.

Variants:

Fork positioner (hydraulic): fork width infinitely adjustable from the cab; essential for changing pallet formats and industrial applications

Wide forks: for oversized loads such as formwork elements, steel beams, pipe bundles

Side shift: horizontal movement of the load without moving the machine; precise positioning in warehouses and during assembly work

Load hook and winch – the crane function

A load hook with a freely suspended load turns the telehandler into lifting equipment subject to occupational safety rules. A winch additionally allows controlled lowering and lifting from pits or shafts.

Technical requirements for operation:

Load attachment with lifting gear (chains, round slings) in line with applicable Slovak safety rules

A freely suspended load must not be travelled with – the machine must be stationary

Winch attachments require their own inspection in line with applicable Slovak safety rules and STN EN standards, in addition to the telehandler inspection

Work basket – MEWP function with 360 degree slewing

The work basket with CE approval to EN 280 turns the telehandler into an aerial work platform. Load capacity typically 200 – 350 kg (1–2 persons + tools). On a roto telehandler the basket rotates with the superstructure – full 360 degree positioning without repositioning the machine.

Critical legal point: when operating with a personnel basket, the requirements of EN 280 apply in full – including inspections and tests of technical equipment (Decree No. 508/2009 Coll.), the required operator competence and operating instructions for carrying persons. The operator must explicitly reflect this in the risk assessment under Government Regulation No. 392/2006 Coll. (work equipment).

Bucket – earthmoving and material handling

Tipping bucket (standard): for sand, gravel, soil, rubble; volume 0.3 – 1.2 m3 depending on model

High-tip bucket: empties over obstacles and into high containers; tipping height up to 3.5 m above ground

Grab bucket: for lumpy material such as stones, tree stumps, demolition debris; hydraulically closing

Bucket with integrated weighing: for recycling, landfills and bulk material intake with billing accuracy

Concrete skip and mortar container

For concreting on hard-to-reach floor slabs and in shaft structures. Capacity 0.3 – 1.5 m3. Emptied via a slide gate, controlled from the cab or by pull cord. An alternative to a stationary crane for small quantities and frequent changes of position.

Clamp forks and pipe grab

For cylindrical loads: concrete pipes, steel pipes, logs, coils. Clamping jaws close hydraulically; the load is held in the clamp without lifting gear. Advantage over a load hook: no slinger required, faster handling, more precise positioning.

Sweeper and snow clearing

Sweeper attachments with a hydraulically driven brush set for site access roads, yards and open areas. Working width 1.5 – 2.5 m. Snow plough blade as the counterpart for winter operation.

Telehandlers with a complete, manufacturer-compliant attachment set achieve 15 – 25 % higher prices on the used market than single machines without accessories. The reason: the buyer takes over a ready-to-use system with documented CE conformity – and does not have to source attachments or check compatibility.

For your planning this means: renting instead of buying protects liquidity. On resale, attachments increase the residual value of the overall package disproportionately.

• Machinery Directive 2006/42/EC – CE conformity for the carrier-attachment combination; manufacturer approval required

• EN 1459-1:2017 – the load chart must show the attachment weight as a deduction

• Inspections and tests of technical equipment (Decree No. 508/2009 Coll.) – cover all attachments in use

• Occupational safety rules (Act No. 124/2006 Coll.) – additional inspection for load hook and winch operation

• EN 280:2013+A1:2015 – applies in full for personnel basket operation

Luibl supplies attachments only with:

• manufacturer approval for the specific carrier machine (in writing)

• CE declaration of conformity for the combination

• operating manual in German

• an entry in the carrier machine's documentation

Advice on the optimum attachment configuration based on the application profile, the carrier machine's hydraulic data and budget. Packages of carrier machine + attachments can be offered as overall financing on request.
