3.8-tonne Electric Forklift | EP EFL382X5 4800 mm



EP EFL382X5 Hire – Electric Forklift with 3.8 t Capacity and 4.8 m Triplex Mast
The EP EFL382X5 is an electric counterbalance forklift with a lifting capacity of 3,800 kg and a modular lithium-ion battery design. In the version with triplex full free lift mast and 4.8 m lift height, it meets the requirements of standard high-bay warehouses where the 4.5 m variant already reaches its limits. At Luibl Rental you can hire the EFL382X5 at short notice, across Europe and including maintenance and service from a single source.
EP EFL382X5 Technical Data (Triplex 4.8 m)
| Specification | Value |
|---|---|
| Rated capacity | 3,800 kg |
| Lift height (triplex full free lift mast) | 4.80 m |
| Free lift (without/with load backrest) | 1.595 m / 1.190 m |
| Drive | Electric, AC drive motor 16 kW (S2 60 min), lift motor 30 kW (S3 15 %) |
| Battery | Lithium-ion 80 V/280 Ah, optional 80 V/560 Ah (2nd module) |
| Service weight | 5,350 kg |
| Dimensions (L x W x H, overhead guard) | 3.87 m x 1.25 m x 2.16 m |
| Travel speed laden/unladen | 15 / 16 km/h |
| Max. gradeability laden/unladen | 16 % / 20 % |
| Tyres | Solid rubber |
| Ground clearance | 150 mm (centre of wheelbase) |
| Turning radius | 2.52 m |
| Sound pressure level at operator position | < 74 dB(A) |
| Certification | CE |
Applications of the EP EFL382X5 with 4.8 m Mast
Standard high-bay warehouses
With a lift height of 4.8 m, the EFL382X5 reaches additional racking levels without the need for a special narrow-aisle truck. This makes this variant a common intermediate step for warehouses with higher racking.
Distribution centres with high turnover
With high pallet throughput, the additional lift reserve compared to the 4.5 m variant provides more flexibility when storing goods in different racking zones.
Combined use in the hall and yard
The high ground clearance of 150 mm and the solid rubber tyres allow switching between hall floors and uneven outdoor areas without changing tyres.
Multi-shift operation in busy warehouses
The optional second battery module enables continuous operation without battery changes, even under intensive use across several shifts.
Modular Lithium-Ion Battery System
The EFL382X5 is supplied as standard with one lithium battery module (80 V/280 Ah). Where greater endurance is required, for example in distribution centres with high order frequency, a second module can be retrofitted, doubling capacity to 560 Ah. This reduces downtime caused by low battery charge and allows adjustment to seasonal peaks without having to hire an additional machine.
Hire or Buy the EP EFL382X5?
| Criterion | Hire from Luibl Rental | Purchase |
|---|---|---|
| Capital commitment | none, predictable hire costs | high investment |
| Maintenance & service | included | own responsibility |
| Availability | at short notice, across Europe | delivery time depends on manufacturer |
| Flexibility when requirements change | switch to a different lift height (4.5 m / 6.0 m) possible | fixed to one mast size |
| Makes sense for | project-related, seasonal requirements | permanent, high-frequency use |
Why Hire the EP EFL382X5 from Luibl Rental?
- Modular lithium-ion system: capacity can be expanded from 280 Ah to 560 Ah as required
- Short-notice availability: prompt feedback on price and delivery date after your enquiry
- Europe-wide use: transport and set-up can also be organised across national borders
- Maintenance & service included: no hidden follow-up costs
- Maintenance-free battery: opportunity charging without a fixed charging cycle
Frequently Asked Questions about the EP EFL382X5 (4.8 m)
What is the lifting capacity of the EP EFL382X5?
The EFL382X5 lifts a maximum of 3,800 kg at a load centre distance of 500 mm.
Is the 4.8 m variant sufficient for my high-bay warehouse?
The 4.8 m variant covers most standard high-bay requirements. For even greater storage heights, Luibl Rental also offers a 6.0 m variant of the EFL382X5.
How long does the battery last in shift operation?
With the standard module (280 Ah), shift operation with opportunity charging is possible; for continuous multi-shift operation, the optional second battery module (560 Ah in total) is recommended.
Is the EFL382X5 also suitable for outdoor use?
Yes, the solid rubber tyres and the ground clearance of 150 mm allow use in yard and ramp areas.
How quickly is the EP EFL382X5 available?
If available in our rental fleet, we deliver at short notice across Europe by appointment.
Enquire about the EP EFL382X5 now
Check the current availability of the EP EFL382X5 with 4.8 m triplex mast for your project. Our team will get back to you promptly with price and delivery date.
Use and Benefits
The electric drive allows emission-free operation at the place of use.
Check availability now and request a quote.
